Spring Driven Aluminum Hose Reel 1/4inx50ft 300PSI (P-LP-150-AL)
by Coxreels
Coxreels P-LP-150-AL Spring Rewind Hose Reel for air/water: 1/4" I.D., 50' hose, 300 PSI
Product Specification
Item #
P-LP-150-AL
Dimensions
Height: 18.63"
Width: 6.75"
Additional product details
Vendor Item #
P-LP-150-AL
Industrial Category
Pneumatics
Industrial Subcategory
Hose Reels
Industrial Subtype
Spring Return Hose Reels
Country of Origin
USA
Currency Code
Dollars
Item Length (inches)
17.13
Item Quantity
1
Item Weight (lbs)
25
Ordering Quantity
1
Product Series
Alumi-Pro Series
Spec 01
ID: 1/4"
Spec 02
OD: 1/2"
Spec 03
Length: 50'
Spec 04
Reel Inlet: 1/4" (F)NPT
Spec 05
Hose Material: PVC
Spec 06
PSI: 300
UPC Number
0674255729018
Manufactured By
Coxreels
Other Details:
- 1/4" ALUMINUM BASE - Sturdy single pedestal design with solid one piece aluminum base and support post, no weld, for maximum stability and professional grade strenght without the weight.
- 1” solid steel axle & lubricated precision bearings for smooth rotation
- CARTRIDGE MOTOR - Lubricated and enclosed cartridge-style motor is easily removable for safe and convenient maintenance. Precision coil spring factory tuned and matched to application for longest life cycle and performance.
- CNC SPUN DISCS - Heavy duty CNC robotically spun and ribbed discs with rolled edges for greater strength, durability, hose protection and operator safety.
- Durable proprietary CPC™ powder coat process
- External fluid path with machined from solid brass 90° full-flow NPT swivel inlet
- Guide arm adjusts to wall, floor, vehicle & overhead positions
- Industrial strength CPC™ powder coated aluminum construction
- Leading 2-year manufacturer's limited warranty
- Made in the U.S.A. - Sold & Supported Worldwide
- MULTI-POSITION GUIDE ARM - Versatile aluminium guide arm adjusts to wall, floor, ceiling, and vehicle mounting positions.
- OTHER FEATURES INCLUDE - long lasting, chip resistant and rust inhibiting CPC powder coat finish, adjustable solid rubber hose stop, and sturdy permanently lubricated precision bearings.
- Professional grade heavy duty steel construction
- PVC red hose
- Rolled edges & ribbed discs provide strength & safety
- Single pedestal reel for applications that require professional grade strength without the weight
- Spring Rewind
- SWIVEL - Machined from solid brass 90◦ full-flow NPT swivel for simple seal maintenance and fast and easy hose installation. No need to remove the reel from its mount.
- Swivel Seals: NITRILE
