34° Clipped head framing nailer kit (8234N)
by King Canada
34 degree clipped head framing nailer kit
Product Specification
Item #
8234N
Dimensions
Height: 14.50"
Width: 4.25"
Additional product details
Vendor Item #
8234N
Industrial Category
Pneumatics
Industrial Subcategory
Pneumatic Tools
Industrial Subtype
Air Nailers
Air consumption
5-8 CFM (70-120 PSI)
Assembled dimensions (LxWxH) / Weight
19'' x 4-1/4'' x 14-1/2'' / 9.5 lbs
Item Length (inches)
19
Item Quantity
1
Item Weight (lbs)
9.5 lbs
Longitudinal feed range
100
Moulding feed rate
.113'' - .131''
Nail diameter range
34°- 11-1/2 - 10-1/4 Ga.
Nail size
2-3/16'' - 3-9/16''
Nail size range
120 /min @ 90 PSI
Oil capacity (l)
70-120 PSI
Overall width across forks
22'' x 7'' x 19'' / 19 lbs
Product Series
PERFORMANCE PLUS
Range of spindle speeds
Craftsman-34° / dewalt-31° / max-34° / porter-cable-34° / senco-34°
Spec 01
Nail range: 34°- 11-1/2 - 10-1/4 Ga.
Spec 02
Nail size range: 2-3/16" - 3-9/16"
Spec 03
Nail diameter range: .113" - .131"
Spec 04
Recommended nails: Craftsman-34° / dewalt-31° / max-34° / porter-cable-34° / senco-34°
Spec 05
Magazine capacity: 100
Spec 06
Operating pressure: 70-120 PSI
Spec 07
Air consumption: 5-8 CFM (70-120 PSI)
Spec 08
Nailer discharge rate: 120 /min @ 90 PSI
Spec 09
Assembled dimensions (LxWxH) / Weight: 19" x 4-1/4" x 14-1/2" / 9.5 lbs
Spec 10
Package dimensions (LxWxH) / Weight: 22" x 7" x 19" / 19 lbs
UNSPSC Number
44121615
UPC Number
7 72995 00522 2
Manufactured By
King Canada
Other Details:
- 1/4" Air inlet
- 360º directional air deflector
- Comes with safety glasses, oiler, hex. keys and carrying case
- It is recommended to use Senco 34° nails
- Powerful framing nailer drives standard 34° clipped head nails
- Protective nose tip for decking
- Serrated nose tip for positive grip when toe nailing
- Special hardened driver for long, trouble free performance
- Trigger for sequential and bump firing modes
