17" Drill press with safety guard (KC-118FC-LS)
by King Canada
17" Floor model drill press with safety guard and limit switch
Downloads
Product Specification
Item #
KC-118FC-LS
Dimensions
Height: 42.00"
Width: 25.50"
Additional product details
Vendor Item #
KC-118FC-LS
Industrial Category
Power Tools
Industrial Subcategory
Power Drills
Industrial Subtype
Floor Standing and Bench Mounted Drill Presses
Assembled dimensions (LxWxH) / Weight
13-3/4'' x 25'' x 64'' / 185 lbs
Capacity
3/4''
Chuck size
5/8''
Item Length (inches)
12.125
Item Quantity
1
Item Weight (lbs)
127 lbs
Max. Distance chuck to table
44''
Max. Distance from chuck to column
23-3/4''
Moteur
12.5 Amp.@110V, 6.25 Amp.@220V
Package dimensions (LxWxH) / Weight
54-3/4'' x 21'' x 11'' / 200 lbs
Pre-wired
110V
Product Series
KING INDUSTRIAL
Qty
65 mm
Spec 01
Capacity: 3/4"
Spec 02
Chuck size: 5/8"
Spec 03
Swing: 17"
Spec 04
Stroke: 3-1/4"
Spec 05
Max. Distance from chuck to table: 23-3/4"
Spec 06
Max. Distance from chuck to base: 44"
Spec 07
Table size: 13-3/4"
Spec 08
Spindle taper: MT #2
Spec 09
Quill diameter: 65 mm
Spec 10
Speeds: 16 (240-3,400) RPM
Spec 11
Motor: 12.5 Amp.@110V, 6.25 Amp.@220V
Spec 12
Voltage: 110V/220V, 1 phase, 60 Hz
Spec 13
Pre-wired at: 110V
Spec 14
Assembled dimensions (LxWxH) / Weight: 13-3/4" x 25" x 64" / 185 lbs
Spec 15
Packaging dimensions (LxWxH) / Weight: 54-3/4" x 21" x 11" / 200 lbs
Speed (wheel / motor)
16 (240-3,400) RPM
Spindle stroke
MT #2
Steel drum capacity
3-1/4''
Suction head lift
17''
Table inserts
13-3/4''
UNSPSC Number
23241801
UPC Number
7 72995 01151 3
Variable speeds (wood)
110V/220V, 1 phase, 60 Hz
Manufactured By
King Canada
Other Details:
- 16 Speeds
- 45° tilting table for angular drilling
- Cast-iron pulleys reduce vibrations
- Light socket incorporated into drill press head (standard light bulb not included)
- Line interruption electro-mechanical switch needs a restart after a power failure
- Non-slip rubber feed handles
- Powerful 1 HP Motor
- Safety guard with limit switch protection
- Spindle is supported by high quality ball bearings
